GEDORE RED R78900400 torque spanner 3/4" 80-400 Nm - 3301219

Name: GEDORE RED R78900400 torque spanner 3/4" 80-400 Nm - 3301219
Brand: GEDORE RED
SKU: 02970483
Price: 254.8 EUR
Availability: PreOrder

254.80 tax incl.

€210.58 excl. VAT (incl. all environmental contributions)

GEDORE RED R78900400 torque spanner 3/4" 80-400 Nm - 3301219

€254.80

On order: delivered from 30/05/2026

each

Ordered before 20:00 - delivered as of 30/05/2026
Free shipping
Delivery by DHL
Delivered from Belgium

Product information

Product description

Controlled tightening of screws from 5 to 25 Nm
Repeatability and precision
Clear audible and tactile signal when the set value is reached
Controlled clockwise and anticlockwise tightening
Version: Adjustable torque spanner with square drive and integrated ratchet function
Square drive with ratchet mechanism
Torque is set by turning the handle
The set value is locked via the lock at the end of the handle
Highly legible scale with magnifying glass for Nm, plus 1/10 scale for exact setting
Accuracy: +/-3 % tolerance of the set scale value
Torque spanner with test certificate in accordance with DIN EN ISO 6789

Key features according to our expert

Min. tightening torque: 80 Nm
Drive profile size: 3/4"
VDE approved: No
With safety colour code 1000V: Not applicable
ESD: No
Adjustable torque range: 80-400 Nm
Max. tightening torque: 400 Nm

Specifications / All features

Brand: GEDORE RED
02970483
EAN: 4060833012195
Supplier number: GEDORE RED 3301219

Min. tightening torque: 80 Nm
Drive profile size: 3/4"
Vde approved: No
With safety colour code 1000v: Not applicable
Esd: No
Adjustable torque range: 80-400 Nm
Max. tightening torque: 400 Nm
Head width 1 [mm].: 62.5 mm
Drive square [inch]: 3/4"
Vernier nm: 1 Nm
Fixed setting: No
Drive type/drive: Piercing square with pin
Tightening direction: Left and right
Test certificate: DIN EN ISO 6789-2:2017
Head height 1 [mm]: 38 mm
Precision +/-: +/- 3 %
Distance housing - square centre: 31 mm
Overall length [mm]: 680 mm
Retrieval angle: 10 °
Torque (min.) [nm].: 80 Nm
Calibration length: 583.2 mm
Torque range (min./max.) [nm].: 80 Nm - 400 Nm
Turn-off mechanism: Short road clearance
Target groups: Automotive Industry Construction and Commercial Vehicles Consumer Energy Mechanical Engineering Workshop Service Agriculture Oil and gas Utilities
Drive square [metric]: 20 mm
Scope: AssemblyMaintenance and repair
Implementation: Piercing square with pin
Scale: 10
Number of teeth: 36
Torque (max.) [nm].: 400 Nm
