Product description: Deep groove ball bearings are particularly versatile They are simple in design, not removable, suitable for high to very high speeds and are very robust in operation, requiring little maintenance Deep raceways and close contact between raceways and balls make deep groove ball bearings suitable not only for radial loads, but also for axial loads in both directions, even at high speeds
Key features according to our expert
Inner diameter: 20 mm
Width: 14 mm
Number of rows: 1
Seal (bearing): Single-sided sealed
Material (bearing seal): Rubber
Radial clearance: C3
Material (bearing): Steel
Material (cage): Brass (sheet)
Bore type: Cylindrical
High temperature: No
Outer diameter: 47 mm
Specifications / All features
Brand:
SKF
01011714
EAN:
7316571819259
Supplier number:
SKF 6204-RSH/C3
Inner diameter
20 mm
Width
14 mm
Number of rows
1
Seal (bearing)
Single-sided sealed
Material (bearing seal)
Rubber
Radial clearance
C3
Material (bearing)
Steel
Material (cage)
Brass (sheet)
Bore type
Cylindrical
High temperature
No
Outer diameter
47 mm
Matched arrangement
No
Tolerance class
Normal
Radial internal clearance
C3
Basic static load rating
6.55 kN
Material, bearing
Bearing steel
Relubrication feature
Without
Skf performance class
SKF Explorer
Lubricant
None
Sealing type
Contact
Cage
Sheet metal
Locating feature, bearing outer ring
None
Filling slots
Without
Coating
Without
Sealing
Seal on one side
Limiting speed
10,000 r/min
Bore diameter
20 mm
Basic dynamic load rating
13.5 kN
Outside diameter
47 mm
