Product description:
- Angular contact bearing, four-point contact ball bearing
SKF QJ 304 LA/P63 four-point contact ball bearing with 35° contact angle 20x52x15 mm
Key features according to our expert
- Inner diameter: 20 mm
- Width: 15 mm
- Axial clearance: C3
- Material (cage): Brass (solid)
- Outer diameter: 52 mm
Specifications / All features
- Brand: SKF
- EAN: 7316571598499
- Supplier number: SKF QJ 304 LA/P63
- Inner diameter
- 20 mm
- Width
- 15 mm
- Axial clearance
- C3
- Material (cage)
- Brass (solid)
- Outer diameter
- 52 mm
- Axial internal clearance
- C3
- Material, bearing
- Bearing steel
- Cage
- Machined metal
- Lubricant
- None
- Relubrication feature
- Without
- Matched arrangement
- No
- Basic static load rating
- 20 kN
- Contact type
- Four-point contact
- Ring type
- Two-piece inner ring and one-piece outer ring
- Locating feature, bearing outer ring
- None
- Sealing
- Without
- Bore diameter
- 20 mm
- Contact angle
- 35.000000000087 °
- Limiting speed
- 24,000 r/min
- Number of rows
- 1
- Basic dynamic load rating
- 29.6 kN
- Coating
- Without
- Outside diameter
- 52 mm
- Universal matching bearing
- No
