FLUKE 719 PRO 30G electric pressure calibrator - 4353218

Scope of delivery

• Electrical pressure calibrator, 30 PSIG
• Test leads with alligator clips
• Printed version of user manual and user manual on CD-ROM in 14 languages
• Moisture separator
• Carrying case
• 1/4 inch NPT to 1/4 inch ISO adapter
• Accessory and hose set with (2) 1/8 inch quick-fit adapters and 1 metre hose
• Traceable calibration certificate

Product description:

• The 719Pro includes a fully functional loop calibrator that generates, simulates and measures mA signals and more, making it the ideal measurement tool for calibrating high-precision transmitters, pressure switches and pressure gauges.
• Have the ultimate measurement flexibility with a large backlit screen displaying three parameters simultaneously:
  • Pressure measurement from internal or external sensor
  • Generated/simulated or measured mA values
  • Temperature measured by optional RTD thermocouple

Key features

• Unique integrated electric pump for one-handed pressure calibration
• Easily test pressure switches using switch test function
• Fine regulator for precise pressure adjustment for easy and accurate pressure calibration
• Highly accurate, high performance (0.025 %) for calibration of reference pressure transmitters
• Pressure ranges of 30 PSI, 150 PSI and 300 PSI
• Programmable pump limit pressure calibrator:
  • Prevents overpressure
  • Allows user to set desired pressure values for pumping
• Expansion of pressure measuring range using one of 29 750P pressure modules
• Pump cleaning vents reduce pump failures caused by moisture and liquids
• Unit is equipped with a moisture separator to reduce the risk of liquid damage in high-risk applications
• Accurate temperature measurements with optional RTD thermocouple
