What is the measurement range of the Fluke i30s current clamp?

It measures AC current from 30 mA to 20 A AC RMS and DC current from 30 mA to 30 A DC across a frequency range from DC to 100 kHz.

Which instruments can this current clamp be connected to?

It connects directly to oscilloscopes via a BNC connector or to other recording instruments using the supplied 4 mm adapter.

What is the maximum conductor size for the Fluke i30s?

The clamp accommodates conductors up to a maximum diameter of 19 mm.

What is the safety rating of the Fluke i30s?

The current clamp has a safety rating of CAT III 300 V.

How is the Fluke i30s powered?

It is powered by a standard 9 V alkaline battery (PP3/MN1604) providing 30 hours of operation.

FLUKE i30s AC/DC current clamp - 2584935

Name: FLUKE i30s AC/DC current clamp - 2584935
Brand: FLUKE
SKU: 02951795
Price: 1127.23 EUR
Availability: PreOrder

Supplier number: FLUKE 2584935 | EAN 0095969345101

Recommended Retail Price €1,190.80

1,127.23 tax incl.

€931.59 excl. VAT (incl. all environmental contributions)

On order: delivered from 08/10/2026

Ordered before 20:00 - delivered as of 08/10/2026
Free shipping
Delivery by DHL
Delivered from Belgium

✆ Talk to a specialist

How does it work?

Purchase Fluke products during the promotion period.
Spend more than €100 excl. VAT? You will earn points based on the value of your purchase: €1 = 1 point.
Redeem your points for a free gift or save them for a higher-value gift.
Register your purchase via the Fluke registration page.
Fluke promotions are recognisable by the promotion label on the product page. Click the label to discover all available Fluke promotions.

Choose your free gift

The more you spend, the greater the reward. See below which free Fluke instruments you can choose based on the number of points you have earned.

Fluke Promotion 2026 - Receive free Fluke instruments

Accurate current measurements with Fluke I30S

Practical benefits

Versatile AC and DC measurement: Advanced Hall effect technology allows you to measure both DC and AC current up to 30A non-intrusively without breaking the circuit.
Wide bandwidth to 100 kHz: With a frequency range up to 100 kHz, you capture fast current transients and complex waveforms cleanly on your oscilloscope.
Direct connection with BNC connector: The integrated 2 m cable with a BNC connector lets you hook directly into oscilloscopes and data loggers for immediate signal capture.

In a nutshell

The right choise for

With the Fluke I30S AC/DC current clamp, you measure both ac and DC currents up to 30A accurately without breaking the electrical circuit. Thanks to advanced Hall effect technology and a wide frequency range up to 100 kHz, you cleanly capture fast current transients and complex waveforms on your oscilloscope. The integrated 2 m cable with a bnc connector allows direct connection to oscilloscopes and data loggers for seamless diagnostics in automotive, industrial, and power electronics applications. Accommodating conductors up to 19 mm, rated cat III 300 V, and powered for up to 30 hours by a single 9V battery, it delivers dependable, non-intrusive measurements with complete confidence.

Product information FAQ

€1,127.23

tax incl.

Product description:

The i30s current clamp uses Hall Effect technology to measure both direct and alternating current.
The i30s can be used with oscilloscopes and other suitable recording instruments to accurately measure current without the need to interrupt the circuit.

Key features

Current range: 30 mA to 30 A DC, 30 mA to 20 A AC (rms)
Frequency range: DC up to 100 kHz (-0.5 dB)
Safety classification CAT III 300 V

Brand FLUKE
02951795
EAN 0095969345101
Supplier number FLUKE 2584935

Frequently asked questions about this product

Answered by specialists

What is the measurement range of the Fluke i30s current clamp?: It measures AC current from 30 mA to 20 A AC RMS and DC current from 30 mA to 30 A DC across a frequency range from DC to 100 kHz.
Which instruments can this current clamp be connected to?: It connects directly to oscilloscopes via a BNC connector or to other recording instruments using the supplied 4 mm adapter.
What is the maximum conductor size for the Fluke i30s?: The clamp accommodates conductors up to a maximum diameter of 19 mm.
What is the safety rating of the Fluke i30s?: The current clamp has a safety rating of CAT III 300 V.
How is the Fluke i30s powered?: It is powered by a standard 9 V alkaline battery (PP3/MN1604) providing 30 hours of operation.
