Application Controlled screw tightening in the range 25 - 120 Nm / 18 - 90 lbf-ft
For use in almost all industrial (production) environments
Design Classified according to DIN EN ISO 6789-22017 Type II Class A, incl traceable test certificate, calibrated with a maximum permissible deviation of +/- 3% and thus more accurate than the /- 4% prescribed by the standard, 1/2" square with ball lock DIN 3120 - A 12.5
ISO 1174
Automatic stop with tactile and audible signal
Double scale with 5 Nm and 5 lbf-ft graduations
With push-button release
Technical advantages/function Light and robust - housing made of high-quality aluminium alloy
No shifting of set values and therefore no influence on accuracy by working with both hands or outside the handle (as with conventional torque spanners).
Both the drive square and the pivot point are on one shaft, so lengthening the spanner does not affect the tightening value.
Extremely low wear due to force reduction on the lever mechanism
Forged lever chain from the in-house GEDORE quality forge
High precision, even in heavy continuous use
Long service life and long service life
Simple operation - quick and reliable tightening of the set torque
Convenient adjustment using an attractively designed, captive adjustment knob on the handle end
Single or double drive square for controlled clockwise and/or anticlockwise tightening
