Product description
- Controlled tightening of screws from 5 to 25 Nm
- Repeatability and precision
- Clear audible and tactile signal when the set value is reached
- Controlled clockwise and anticlockwise tightening
- Version: Adjustable torque spanner with square drive and integrated ratchet function
- Square drive with ratchet mechanism
- Torque is set by turning the handle
- The set value is locked via the lock at the end of the handle
- Highly legible scale with magnifying glass for Nm, plus 1/10 scale for exact setting
- Accuracy: +/-3 % tolerance of the set scale value
- Torque spanner with test certificate in accordance with DIN EN ISO 6789
Key features according to our expert
-
Min. tightening torque: 110 Nm
-
Drive profile size: 3/4"
-
VDE approved: No
-
With safety colour code 1000V: Not applicable
-
ESD: No
-
Adjustable torque range: 110-550 Nm
-
Max. tightening torque: 550 Nm
Specifications / All features
-
Brand:
GEDORE RED
-
02970484
-
EAN:
4060833012201
-
Supplier number:
GEDORE RED 3301220
- Min. tightening torque
- 110 Nm
- Drive profile size
- 3/4"
- Vde approved
- No
- With safety colour code 1000v
- Not applicable
- Esd
- No
- Adjustable torque range
- 110-550 Nm
- Max. tightening torque
- 550 Nm
- Head width 1 [mm].
- 69.0 mm
- Drive square [inch]
- 3/4"
- Vernier nm
- 1 Nm
- Fixed setting
- No
- Drive type/drive
- Piercing square with pin
- Tightening direction
- Left and right
- Test certificate
- DIN EN ISO 6789-2:2017
- Head height 1 [mm]
- 38 mm
- Precision +/-
- +/- 3 %
- Distance housing - square centre
- 34.5 mm
- Overall length [mm]
- 960 mm
- Retrieval angle
- 10 °
- Torque (min.) [nm].
- 110 Nm
- Calibration length
- 853.7 mm
- Torque range (min./max.) [nm].
- 110 Nm - 550 Nm
- Turn-off mechanism
- Short road clearance
- Target groups
- Automotive Industry Construction and Commercial Vehicles Consumer Energy Mechanical Engineering Workshop Service Agriculture Oil and gas Utilities
- Drive square [metric]
- 20 mm
- Scope
- AssemblyMaintenance and repair
- Scale
- 10
- Number of teeth
- 36
- Torque (max.) [nm].
- 550 Nm
