INGERSOLL RAND 2146Q1MAX-6 pneumatic impact spanner square 3/4" 2712Nm with 6" extended anvil

Name: INGERSOLL RAND 2146Q1MAX-6 pneumatic impact spanner square 3/4" 2712Nm with 6" extended anvil
Brand: INGERSOLL RAND
SKU: 03212124
Price: 583.6 EUR
Availability: PreOrder

Supplier number: INGERSOLL RAND 2146Q1MAX-6 | EAN 0663023164601

583.60 tax incl.

€482.31 excl. VAT (incl. all environmental contributions)

On order: delivered from 20/10/2026

Ordered before 20:00 - delivered as of 20/10/2026
Free shipping
Delivery by DHL
Delivered from Belgium

✆ Talk to a specialist

Product information

€583.60

tax incl.

Key features according to our expert

Max. tightening torque: 1763 Nm
Tool holder size: 3/4"
Tool holder type: External square
Connection size (air): 3/8"
Speed: 5500 rpm
Max. breakeway torque: 2712 Nm

Product description

2700 Nm breakaway torque and 1970 Nm tightening torque in a compact impact spanner weighing only 3.5 kg
Innovative pressure gauge improves productivity and extends service life
Ability to quickly set optimum power settings increases productivity and speed
6-lobe motor delivers extra power
Cold-forged double hammer mechanism and motor deliver more torque, durability and efficiency
Optimised airflow for maximum performance when using this pneumatic impact wrench
Designed to withstand heavy use in harsh environments: steel hammer housing withstands drops
Hard anodised end plate for improved durability
Improved ergonomic comfort with a unit compact enough to access tight spaces
Quiet Technology reduces tool noise, saving your ears without compromising on power
Forward/reverse one-handed operation and featherweight trigger ensure maximum control
Easier access to the grease nipple for faster maintenance and less downtime
Optimised for the vehicle repair industry, body shops, general industrial use, MRO (Maintenance, Repair and Overhaul), railways, heavy machinery, oil and gas, shipbuilding and construction

All Features

Max. tightening torque: 1763 Nm
Tool holder size: 3/4"
Tool holder type: External square
Connection size (air): 3/8"
Speed: 5500 rpm
Max. breakeway torque: 2712 Nm
Anvil size (in): 3/4"
Max. speed ( min-1): 5500
Vibration (m/s²): 8.4
Breakaway torque max (nm): 2712
Max. release torque (nm): 1966
Stroke frequency (1 min): 1075
Forward/fast torque (nm): 1763
Sound pressure level (db (a)): 88.8 / 99.8
Air consumption (l/min): 396
Length (mm): 368
Connection wire: 1/2" NPT
Weight (kg): 4.58
Working pressure (bar): 6.2
Height (mm): 208
Width (mm): 89
Special features: Quiet, Air Pressure Gauge, Cold Forged Twin Hammers, Hard Anodized Wear Plates
