Which materials is this burr designed for?

This burr is specifically designed for machining steel and cast steel.

What is the shank diameter of this burr?

It features a cylindrical shank with a diameter of 6 mm.

What are the dimensions of the burr head?

The flame-shaped head has a diameter of 16 mm and a cutting length of 35 mm.

What is the benefit of the STEEL cut geometry?

It delivers significantly higher stock removal while reducing thermal load on the workpiece.

PFERD B 1635/6 STEEL tungsten carbide high-efficiency burr flame shape B 16x35mm 6mm for steel - 21103436

Name: PFERD B 1635/6 STEEL tungsten carbide high-efficiency burr flame shape B 16x35mm 6mm for steel - 21103436
Brand: PFERD
SKU: 03234196
Price: 106.26 EUR
Availability: PreOrder

Supplier number: PFERD 21103436 | EAN 4007220003039

106.26 tax incl.

€87.82 excl. VAT (incl. all environmental contributions)

On order: delivered from 16/10/2026

Ordered before 20:00 - delivered as of 16/10/2026
Shipping costs €6.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL
Delivered from Belgium

✆ Talk to a specialist

High stock removal with Pferd

Practical benefits

Faster cutting on steel: You remove steel and cast steel rapidly thanks to aggressive tooth geometry.
Stable and precise guidance: The flame shape and 6 mm cylindrical shank give you complete control during milling.
Reduced thermal workload: You protect workpieces from excessive heat while reducing wear on your drive tool.

In a nutshell

The right choise for

With the Pferd b 1635/6 steel burr, you machine steel and cast steel quickly and with complete control. The aggressive steel tooth geometry delivers high stock removal when deburring, chamfering, and preparing weld seams. Featuring a flame shape with a 16 mm diameter and a 35 mm cutting length, it allows you to contour complex shapes, radii, and hard-to-reach inner angles with precision. The cylindrical 6 mm shank ensures stable guidance on your straight grinder or flexible shaft machine, while the reduced thermal load protects your workpiece from excessive heat and minimizes tool wear.

Product information FAQ

€106.26

tax incl.

Key features according to our expert

Diameter: 16 mm
Shape (burr cutter): Flame (H)
Cutting length: 35 mm
Shank type: Cylindrical
Shank size (milling cutter): 6 mm

Product description

PFERD Tungsten carbide high-performance burr STEEL flame B dia. 16x35 mm shank dia. 6 mm for steel

Characteristics

With the innovative STEEL cut, PFERD has developed unique burrs for working with steel and cast steel
They feature tangibly increased aggressiveness and good guidance
They thus ensure safe and precise work
Thanks to their extremely high stock removal rate, burrs with the STEEL cut help users save considerable time when working, thus making them an economically efficient option
Flame-shaped burr according to ISO 7755/8

Advantages:

Up to 50 % higher stock removal rate when used on steel and cast steel in comparison to conventional cross-cut burrs.
Tangibly more aggressive, large chips and very good chip removal through the innovative tooth geometry.
Workpieces are protected through significantly lower thermal load.
The highly accurate concentricity enables impactfree working without creating chatter marks. This considerably reduces wear on the tool and tool drive.

All Features

Diameter: 16 mm
Shape (burr cutter): Flame (H)
Cutting length: 35 mm
Shank type: Cylindrical
Shank size (milling cutter): 6 mm
Rpm up to, hardened refined steels above 1,200 n/mm²: 15000
Rpm of, steels up to 1,200 n/mm²: 9000
Gearing: STEEL
Rpm up to, steels up to 1,200 n/mm²: 15000
Rpm of, hardened refined steels above 1,200 n/mm²: 9000
Processing tasks: Obtaining cut-outs
Workable materials: High-speed steel
Length, toothed: 35
ø shaft metric: 6

Brand PFERD
03234196
EAN 4007220003039
Supplier number PFERD 21103436

Frequently asked questions about this product

Answered by specialists

Which materials is this burr designed for?: This burr is specifically designed for machining steel and cast steel.
What is the shank diameter of this burr?: It features a cylindrical shank with a diameter of 6 mm.
What are the dimensions of the burr head?: The flame-shaped head has a diameter of 16 mm and a cutting length of 35 mm.
What is the benefit of the STEEL cut geometry?: It delivers significantly higher stock removal while reducing thermal load on the workpiece.
