SKF 1322 KM double-row self-aligning ball bearing tapered 110x240x50 mm

SKF
Supplier number: SKF 1322 KM | EAN 7316576605710
This product has been discontinued.

✆ Talk to a specialist


Product information

Product information

Key features according to our expert

  • Inner diameter: 110 mm
  • Width: 50 mm
  • Number of rows: 2
  • Sealing (bearing): Without seals
  • Material (bearing seal): Not applicable
  • Radial clearance: CN (Normal)
  • Material (cage): Brass (solid)
  • Bore type: Tapered
  • Outer diameter: 240 mm

Product description:

  • The double-row self-adjusting ball bearing has two rows of balls and a common spherical raceway in the outer ring
  • This allows the bearing to set itself and is insensitive to misalignment with respect to the bearing housing
  • This bearing is particularly suitable for bearing constructions where significant shaft deflections or misalignments must be taken into account
  • Another advantage of self-aligning ball bearings is that they have the lowest friction of all rolling bearings, so this bearing generates less frictional heat even at higher speeds

All Features

Inner diameter
110 mm
Width
50 mm
Number of rows
2
Sealing (bearing)
Without seals
Material (bearing seal)
Not applicable
Radial clearance
CN (Normal)
Material (cage)
Brass (solid)
Bore type
Tapered
Outer diameter
240 mm
Basic static load rating
72 kN
Retaining feature, inner ring
None
Radial internal clearance
CN
Material, bearing
Bearing steel
Relubrication feature
Without
Reference speed
5,300 r/min
Lubricant
None
Cage
Machined metal
Locating feature, bearing outer ring
None
Tolerance class
Normal
Basic dynamic load rating
163 kN
Sealing
Without
Limiting speed
3,600 r/min
Bore diameter
110 mm
Coating
Without
Outer diameter
240 mm
  • Brand SKF
  • EAN 7316576605710
  • Supplier number SKF 1322 KM
