What are the dimensions of this bearing?

The bearing has an inside diameter of 80 mm, an outside diameter of 140 mm, and a width of 33 mm.

What does the C3 clearance mean on this spherical roller bearing?

A C3 rating indicates greater radial internal clearance than normal, suitable for heavy loads and thermal expansion.

What type of bore does this SKF bearing have?

It features a tapered bore (1:12 taper), designed for mounting on a tapered shaft or with an adapter sleeve.

Can this bearing be relubricated?

Yes, it is designed with relubrication features for easy lubricant replenishment.

Is this bearing sealed?

No, this is an open bearing without integrated seals.

SKF 22216 EK/C3 double-row tapered roller bearing 80 x 140 x 33 mm

Supplier number: SKF 22216 EK/C3 | EAN 7316576652547

Recommended Retail Price €505.60

250.20 tax incl.

€206.78 excl. VAT (incl. all environmental contributions)

On stock - immediately available | we have 7 products in stock.

Ordered before 20:00 - delivered as of 16/10/2026
Free shipping
Delivery by DHL
Delivered from Belgium

↓ Documents (1) ✆ Talk to a specialist

Heavy load performance with Skf bearings

Practical benefits

High combined load support: You accommodate heavy radial and axial forces across two rows of spherical rollers in demanding machinery.
Self-aligning design reduces friction: It automatically compensates for shaft deflection and misalignment to prevent excess heat buildup during continuous operation.
Easy mounting and relubrication: The tapered bore pairs smoothly with adapter sleeves while relubrication features simplify your routine industrial maintenance.

In a nutshell

The right choise for

Keep your heavy industrial machinery running smoothly and reliably with the Skf 22216 EK/C3 double-row spherical roller bearing. Featuring two rows of rollers, it effortlessly handles heavy combined radial and axial loads. The self-aligning design automatically compensates for shaft deflection and misalignment, keeping friction and heat generation to a minimum. Its increased C3 internal clearance prevents bearing seizure during thermal expansion and elevated operating temperatures. The tapered bore makes mounting onto tapered shaft seatings or with adapter sleeves straightforward, while integrated relubrication features simplify routine maintenance to ensure continuous performance and reduced downtime.

Product information FAQ

€250.20

In stock - tax incl.

Key features according to our expert

Inner diameter: 80 mm
Width: 33 mm
Number of rows: 2
Sealing (bearing): Without seals
Material (bearing seal): Not applicable
Radial clearance: C3
Material (cage): Brass (sheet)
Bore type: Tapered
Outer diameter: 140 mm

Product description

Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.

Accommodate misalignment
High load carrying capacity
Relubrication features
Low friction and long service life
Increased wear resistance

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 80 mm
Width: 33 mm
Number of rows: 2
Sealing (bearing): Without seals
Material (bearing seal): Not applicable
Radial clearance: C3
Material (cage): Brass (sheet)
Bore type: Tapered
Outer diameter: 140 mm
Reference speed: 4300
Basic static load rating: 270
Relubrication feature: With
Tolerance class for run-out: P5
Skf performance class: SKF Explorer
Lubricant: None
Cage: Sheet metal
Locating feature, bearing outer ring: Without
Radial internal clearance: C3
Basic dynamic load rating: 243
Sealing: Without
Limiting speed: 6000
Bore diameter: 80
Outer diameter: 140
Tolerance class for dimensions: Normal

Brand SKF
01090366
EAN 7316576652547
Supplier number SKF 22216 EK/C3

Frequently asked questions about this product

Answered by specialists

What are the dimensions of this bearing?: The bearing has an inside diameter of 80 mm, an outside diameter of 140 mm, and a width of 33 mm.
What does the C3 clearance mean on this spherical roller bearing?: A C3 rating indicates greater radial internal clearance than normal, suitable for heavy loads and thermal expansion.
What type of bore does this SKF bearing have?: It features a tapered bore (1:12 taper), designed for mounting on a tapered shaft or with an adapter sleeve.
Can this bearing be relubricated?: Yes, it is designed with relubrication features for easy lubricant replenishment.
Is this bearing sealed?: No, this is an open bearing without integrated seals.
