SKF

SKF 22226 E double-row cylindrical roller bearing 130 x 230 x 64 mm

Recommended Retail Price €1,909.89
945.40 tax incl.
€781.32 excl. VAT (incl. all environmental contributions)
On stock, immediately available. we have 7 products in stock.
each

  • Ordered before 20:00 - delivered as of 16/05/2026
  • Free shipping
  • Delivery by DHL
  • Delivered from Belgium

Product description

Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.

  • Accommodate misalignment
  • High load carrying capacity
  • Relubrication features
  • Low friction and long service life
  • Increased wear resistance
Key features according to our expert
  • Inner diameter: 130 mm
  • Width: 64 mm
  • Number of rows: 2
  • Seal (bearing): Without seal
  • Material (bearing seal): Not applicable
  • Radial clearance: CN (Normal)
  • Material (cage): Brass (sheet)
  • Bore type: Cylindrical
  • Outer diameter: 230 mm
Specifications / All features
  • Brand: SKF
  • EAN: 7316577758521
  • Supplier number: SKF 22226 E
Inner diameter
130 mm
Width
64 mm
Number of rows
2
Seal (bearing)
Without seal
Material (bearing seal)
Not applicable
Radial clearance
CN (Normal)
Material (cage)
Brass (sheet)
Bore type
Cylindrical
Outer diameter
230 mm
Skf performance class
SKF Explorer
Basic static load rating
930
Relubrication feature
With
Reference speed
2600
Candidate for remanufacturing
Yes
Lubricant
None
Cage
Sheet metal
Locating feature, bearing outer ring
Without
Tolerance class for run-out
P5
Radial internal clearance
CN
Basic dynamic load rating
758
Sealing
Without
Limiting speed
3600
Bore diameter
130
Outside diameter
230
Tolerance class for dimensions
Normal
