What are the dimensions of this bearing?

The spherical roller bearing has a 40 mm bore diameter, a 90 mm outer diameter, and a width of 33 mm.

What does the C3 clearance mean for this bearing?

C3 indicates greater radial internal clearance than normal, suitable for higher operating temperatures or press fits.

Can this bearing be relubricated?

Yes, it features built-in relubrication facilities.

What bore type does this bearing have?

This bearing has a cylindrical bore for direct mounting on a cylindrical shaft.

Is this SKF bearing sealed?

No, this is an open bearing without seals.

SKF 22308 E/C3 double-row cylindrical roller bearing 40 x 90 x 33 mm

Supplier number: SKF 22308 E/C3 | EAN 7316571570556

Recommended Retail Price €310.38

153.60 tax incl.

€126.94 excl. VAT (incl. all environmental contributions)

On stock - immediately available

Ordered before 20:00 - delivered tomorrow 15/10/2026
Free shipping
Delivery by DHL
Delivered from Belgium

↓ Documents (1) ✆ Talk to a specialist

Heavy load performance and durability

Practical benefits

High radial load capacity: You accommodate heavy radial forces combined with axial loads effortlessly due to the robust two-row spherical roller design.
Thermal clearance for reliability: You maintain smooth operation during high operating temperatures with the internal C3 radial clearance of your Skf bearing.
Simple relubrication for longevity: You extend machine service life quickly by delivering fresh grease directly through the integrated lubrication features.

In a nutshell

The right choise for

With the Skf 22308 E/C3 two-row spherical roller bearing, you keep heavy industrial installations running smoothly and reliably. This open bearing measuring 40 x 90 x 33 mm with a cylindrical bore is built to accommodate heavy combined radial and axial loads effortlessly. Thanks to its increased C3 radial internal clearance, it maintains smooth operation during thermal expansion and elevated working temperatures, while naturally compensating for shaft deflections and angular misalignments without added friction. Built-in relubrication features make periodic maintenance simple, allowing you to supply fresh grease directly and substantially extend the service life of your rotating machinery.

Product information FAQ

€153.60

In stock - tax incl.

Key features according to our expert

Inner diameter: 40 mm
Width: 33 mm
Number of rows: 2
Sealing (bearing): Without seals
Material (bearing seal): Not applicable
Radial clearance: C3
Material (cage): Brass (sheet)
Bore type: Cylindrical
Outer diameter: 90 mm

Product description

Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.

Accommodate misalignment
High load carrying capacity
Relubrication features
Low friction and long service life
Increased wear resistance

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 40 mm
Width: 33 mm
Number of rows: 2
Sealing (bearing): Without seals
Material (bearing seal): Not applicable
Radial clearance: C3
Material (cage): Brass (sheet)
Bore type: Cylindrical
Outer diameter: 90 mm
Reference speed: 6000
Basic static load rating: 140
Relubrication feature: With
Tolerance class for run-out: P5
Skf performance class: SKF Explorer
Lubricant: None
Cage: Sheet metal
Locating feature, bearing outer ring: Without
Radial internal clearance: C3
Basic dynamic load rating: 155
Sealing: Without
Limiting speed: 8000
Bore diameter: 40
Outer diameter: 90
Tolerance class for dimensions: Normal

Brand SKF
01090394
EAN 7316571570556
Supplier number SKF 22308 E/C3

Frequently asked questions about this product

Answered by specialists

What are the dimensions of this bearing?: The spherical roller bearing has a 40 mm bore diameter, a 90 mm outer diameter, and a width of 33 mm.
What does the C3 clearance mean for this bearing?: C3 indicates greater radial internal clearance than normal, suitable for higher operating temperatures or press fits.
Can this bearing be relubricated?: Yes, it features built-in relubrication facilities.
What bore type does this bearing have?: This bearing has a cylindrical bore for direct mounting on a cylindrical shaft.
Is this SKF bearing sealed?: No, this is an open bearing without seals.
