SKF

SKF 22330 CCJA/W33VA406 double-row cylindrical roller bearing 150 x 320 x 108 mm

Recommended Retail Price €6,795.13
3,364.20 tax incl.
€2,780.33 excl. VAT (incl. all environmental contributions)
On order: delivered from 11/06/2026
each

  • Ordered before 20:00 - delivered as of 11/06/2026
  • Free shipping
  • Delivery by DHL
  • Delivered from Belgium

Product description

Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. This bearing design offers excellent performance in many types of vibrating machinery. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.

  • Accommodate misalignment
  • High load carrying capacity
  • Accommodate very high vibration levels
  • Low friction and long service life
  • Increased wear resistance
Key features according to our expert
  • Inner diameter: 150 mm
  • Width: 108 mm
  • Number of rows: 2
  • Seal (bearing): Without seal
  • Material (bearing seal): Not applicable
  • Radial clearance: C4
  • Material (cage): Surface-hardened sheet steel
  • Bore type: Cylindrical
  • Outer diameter: 320 mm
Specifications / All features
  • Brand: SKF
  • EAN: 7316570628050
  • Supplier number: SKF 22330 CCJA/W33VA406
Inner diameter
150 mm
Width
108 mm
Number of rows
2
Seal (bearing)
Without seal
Material (bearing seal)
Not applicable
Radial clearance
C4
Material (cage)
Surface-hardened sheet steel
Bore type
Cylindrical
Outer diameter
320 mm
Skf performance class
SKF Explorer
Basic static load rating
1760
Relubrication feature
With
Reference speed
1600
Application
For vibratory applications
Lubricant
None
Cage
Surface-hardened sheet metal
Locating feature, bearing outer ring
Without
Candidate for remanufacturing
Yes
Radial internal clearance
C4
Basic dynamic load rating
1539
Sealing
Without
Limiting speed
2000
Bore diameter
150
Outside diameter
320
Tolerance class for dimensions
Normal, bore to P5 and outside diameter P6
