SKF

SKF 22334 CCK/C3W33 double-row tapered roller bearing 170 x 360 x 120 mm

Recommended Retail Price €7,700.16
3,812.20 tax incl.
€3,150.58 excl. VAT (incl. all environmental contributions)
On order: delivered from 28/05/2026
each

  • Ordered before 20:00 - delivered as of 28/05/2026
  • Free shipping
  • Delivery by DHL
  • Delivered from Belgium

Product description

Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.

  • Accommodate misalignment
  • High load carrying capacity
  • Relubrication features
  • Low friction and long service life
  • Increased wear resistance
Key features according to our expert
  • Inner diameter: 170 mm
  • Width: 120 mm
  • Number of rows: 2
  • Seal (bearing): Without seal
  • Material (bearing seal): Not applicable
  • Radial clearance: C3
  • Material (cage): Brass (sheet)
  • Bore type: Tapered
  • Outer diameter: 360 mm
Specifications / All features
  • Brand: SKF
  • EAN: 7316576601521
  • Supplier number: SKF 22334 CCK/C3W33
Inner diameter
170 mm
Width
120 mm
Number of rows
2
Seal (bearing)
Without seal
Material (bearing seal)
Not applicable
Radial clearance
C3
Material (cage)
Brass (sheet)
Bore type
Tapered
Outer diameter
360 mm
Skf performance class
SKF Explorer
Basic static load rating
2160
Relubrication feature
With
Reference speed
1400
Candidate for remanufacturing
Yes
Lubricant
None
Cage
Sheet metal
Locating feature, bearing outer ring
Without
Tolerance class for run-out
P5
Radial internal clearance
C3
Basic dynamic load rating
1863
Sealing
Without
Limiting speed
1800
Bore diameter
170
Outside diameter
360
Tolerance class for dimensions
Normal
