skf_23122cckc4w33

SKF 23122 CCK/C4W33 double-row tapered roller bearing 110 x 180 x 56 mm

Supplier number: SKF 23122 CCK/C4W33 | EAN 7316577610485
Recommended Retail Price €1,322.09
654.40 tax incl.
€540.83 excl. VAT (incl. all environmental contributions)
On order: delivered from 26/11/2026

  • Ordered before 20:00 - delivered as of 26/11/2026
  • Free shipping
  • Delivery by DHL
  • Delivered from Belgium


€654.40
tax incl.

Product information

Key features according to our expert

  • Inner diameter: 110 mm
  • Width: 56 mm
  • Number of rows: 2
  • Sealing (bearing): Without seals
  • Material (bearing seal): Not applicable
  • Radial clearance: C4
  • Material (cage): Brass (sheet)
  • Bore type: Tapered
  • Outer diameter: 180 mm

Product description

  • Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts. Also available on request with special sized bore and/or outside diameters, suitable for reworked shafts and housings.

Avantages

  • Accommodate misalignment
  • High load carrying capacity
  • Relubrication features
  • Low friction and long service life
  • Increased wear resistance

Documents

All Features

Inner diameter
110 mm
Width
56 mm
Number of rows
2
Sealing (bearing)
Without seals
Material (bearing seal)
Not applicable
Radial clearance
C4
Material (cage)
Brass (sheet)
Bore type
Tapered
Outer diameter
180 mm
Skf performance class
SKF Explorer
Basic static load rating
585 kN
Relubrication feature
With
Reference speed
2800 r/min
Candidate for remanufacturing
Yes
Lubricant
None
Cage
Sheet metal
Locating feature, bearing outer ring
Without
Tolerance class for run-out
P5
Radial internal clearance
C4
Basic dynamic load rating
450 kN
Sealing
Without
Limiting speed
3600 r/min
Bore diameter
110 mm
Outside diameter
180 mm
Tolerance class for dimensions
Normal
  • Brand SKF
  • EAN 7316577610485
  • Supplier number SKF 23122 CCK/C4W33
