SKF 3207 A-2RS1TN9/MT33 double-row angular contact ball bearing 35 x 72 x 27 mm with 30° contact angle

Supplier number: SKF 3207 A-2RS1TN9/MT33 | EAN 7316571143156

Recommended Retail Price €199.12

98.40 tax incl.

€81.32 excl. VAT (incl. all environmental contributions)

On stock - immediately available

Ordered before 20:00 - delivered tomorrow 29/09/2026
Shipping costs €6.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL
Delivered from Belgium

↓ Documents (1) ✆ Talk to a specialist

Smooth rotation under combined loads

Practical benefits

Dual row contact design: With a 30° contact angle, you reliably support heavy radial and bidirectional axial loads simultaneously.
Double contact seal protection: The built-in 2RS1 rubber seals keep contaminants out, extending the service life of your Skf bearing.
Lightweight polyamide cage: You achieve reduced friction and quiet running performance during high-speed rotational operations.

In a nutshell

The right choise for

With the Skf 3207 A-2RS1TN9/MT33 double-row angular contact ball bearing, you reliably absorb heavy combined radial and bidirectional axial loads within a compact 35 x 72 x 27 mm footprint. Its 30° contact angle eliminates the need for paired single-row bearings in tight machinery, gearbox, and pump assemblies. Dual-sided 2RS1 rubber contact seals keep out dust and moisture, while the lightweight glass-fibre reinforced polyamide cage reduces friction and vibration during high-speed rotation. Pre-greased at the factory with Skf MT33 lubricant, this bearing is ready for immediate installation, minimising maintenance effort and operational downtime.

Product information FAQ

€98.40

In stock - tax incl.

Key features according to our expert

Inner diameter: 35 mm
Width: 27 mm
Number of rows: 2
Axial clearance: CN (Normal)
Sealing (bearing): Sealed on both sides
Material (bearing seal): Rubber
Material (cage): Plastic
Outer diameter: 72 mm

Product description

Double row angular contact ball bearings, with seals or shields, correspond to a pair of single row angular contact ball bearings in a back-to-back arrangement, while requiring less axial space. Depending on the sealing execution, they can operate at high speeds and are more suitable than deep groove ball bearings for supporting large axial forces in both directions.

High-speed capability
Accommodate relatively high radial loads, high axial loads in both directions and tilting moments
Suitable where a stiff bearing arrangement is required
Require less axial space than equivalent pair of single row angular contact ball bearings
Integral sealing prolongs bearing service life

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 35 mm
Width: 27 mm
Number of rows: 2
Axial clearance: CN (Normal)
Sealing (bearing): Sealed on both sides
Material (bearing seal): Rubber
Material (cage): Plastic
Outer diameter: 72 mm
Matched arrangement: No
Locating feature, bearing outer ring: None
Ring type: One-piece inner and outer rings
Contact type: Normal contact (two-point contact)
Basic static load rating: 30
Sealing type: Contact
Relubrication feature: Without
Skf performance class: SKF Explorer
Lubricant: Grease
Arrangement of contact angle (double-row bearing): Back-to-back (O)
Cage: Non-metallic
Material, bearing: Bearing steel
Sealing: Seal on both sides
Bore diameter: 35
Axial internal clearance: CN
Contact angle: 30
Limiting speed: 6300
Basic dynamic load rating: 40.5
Coating: Without
Outside diameter: 72
Universal matching bearing: No

Brand SKF
01050365
EAN 7316571143156
Supplier number SKF 3207 A-2RS1TN9/MT33

Frequently asked questions about this product

Answered by specialists

What are the dimensions of this angular contact ball bearing?: The bearing has an inside diameter of 35 mm, an outside diameter of 72 mm, and a width of 27 mm.
What loads can this double-row bearing handle?: It accommodates combined radial loads and axial loads in both directions with its 30° contact angle.
What type of sealing does this SKF bearing have?: It features 2RS1 rubber contact seals on both sides to protect against dirt and moisture.
What does the TN9 suffix in the model code indicate?: TN9 indicates a cage made from glass-fibre reinforced polyamide.
Is this ball bearing pre-lubricated upon delivery?: Yes, it comes pre-greased with SKF MT33 lubricant and is ready to install.
