What are the dimensions of this Skf 61907-2RZ ball bearing?

This bearing has an inside diameter of 35 mm, an outside diameter of 55 mm, and a width of 10 mm.

What does the 2RZ designation mean on this bearing?

The 2RZ code means the bearing is equipped on both sides with non-contact rubber and metal seals to keep out debris.

What loads can this single row deep groove ball bearing handle?

It is designed to accommodate both radial and axial loads in both directions at high rotational speeds.

SKF 61907-2RZ single-row groove ball bearing cylindrical 35x55x10 mm

Supplier number: SKF 61907-2RZ | EAN 7316577095114

Recommended Retail Price €115.51

57.20 tax incl.

€47.27 excl. VAT (incl. all environmental contributions)

On stock - immediately available | we have 7 products in stock.

Ordered before 20:00 - delivered as of 14/10/2026
Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL
Delivered from Belgium

↓ Documents (1) ✆ Talk to a specialist

Smooth rotation with the Skf ball bearing

Practical benefits

Effective seal against contamination: The double-sided rubber and metal seals keep lubricant inside while protecting your internal components from dirt.
Low friction at high speeds: Designed for quiet operation, the low-friction single-row raceway delivers consistent efficiency in your machinery.
Dual direction load support: With its deep groove geometry, you easily accommodate both radial and axial loads across demanding applications.

In a nutshell

The right choise for

With the Skf 61907-2RZ single row deep groove ball bearing, you keep rotating shafts running smoothly and reliably. Featuring compact 35X55X10 mm dimensions, a cylindrical bore, and standard normal radial clearance (CN), this steel bearing fits easily into narrow housings where radial space is limited. The dual non-contact 2RZ rubber and metal seals keep lubricant securely inside while providing dependable protection against dust and fine contaminants without creating high frictional drag. This design allows you to handle both radial and axial loads in both directions at high rotational speeds, making it an ideal choice for electric motors, precision gearboxes, and bike hubs.

Product information FAQ

€57.20

In stock - tax incl.

Key features according to our expert

Inner diameter: 35 mm
Width: 10 mm
Number of rows: 1
Sealing (bearing): Sealed on both sides
Material (bearing seal): Rubber/metal
Radial clearance: CN (Normal)
Material (bearing): Steel
Material (cage): Brass (sheet)
Bore type: Cylindrical
High temperature: No
Outer diameter: 55 mm

Product description

Single row deep groove ball bearings with seals or shields are particularly versatile, have low friction and are optimized for low noise and low vibration, which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount, and require less maintenance than many other bearing types. The integral sealing can significantly prolong bearing service life because it keeps lubricant in the bearings and contaminants out.

Integral sealing prolongs bearing service life
Simple, versatile and robust design
Low friction and high-speed capability
Accommodate radial and axial loads in both directions
Require little maintenance

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 35 mm
Width: 10 mm
Number of rows: 1
Sealing (bearing): Sealed on both sides
Material (bearing seal): Rubber/metal
Radial clearance: CN (Normal)
Material (bearing): Steel
Material (cage): Brass (sheet)
Bore type: Cylindrical
High temperature: No
Outer diameter: 55 mm
Matched arrangement: No
Tolerance class: Normal
Radial internal clearance: CN
Basic static load rating: 7.35
Material, bearing: Bearing steel
Relubrication feature: Without
Reference speed: 26000
Lubricant: Grease
Sealing type: Non-contact
Cage: Sheet metal
Locating feature, bearing outer ring: None
Filling slots: Without
Coating: Without
Sealing: Seal on both sides
Limiting speed: 13000
Bore diameter: 35
Basic dynamic load rating: 11.1
Outer diameter: 55

Brand SKF
01011356
EAN 7316577095114
Supplier number SKF 61907-2RZ

Frequently asked questions about this product

Answered by specialists

What are the dimensions of this Skf 61907-2RZ ball bearing?: This bearing has an inside diameter of 35 mm, an outside diameter of 55 mm, and a width of 10 mm.
What does the 2RZ designation mean on this bearing?: The 2RZ code means the bearing is equipped on both sides with non-contact rubber and metal seals to keep out debris.
What loads can this single row deep groove ball bearing handle?: It is designed to accommodate both radial and axial loads in both directions at high rotational speeds.
What type of bore and internal clearance does this bearing have?: This bearing features a cylindrical bore and standard normal radial internal clearance (CN).
