SKF 81138 M single-row cylindrical roller bearing single acting 190 x 240 mm

SKF
Supplier number: SKF 81138 M | EAN 7316572428818
This product has been discontinued.

✆ Talk to a specialist


Product information

Product information

Key features according to our expert

  • Inner diameter: 190 mm
  • Width: 37 mm
  • Number of rows: 1
  • Material (cage): Brass (solid)
  • Outer diameter: 240 mm

Product description:

  • Cylindrical roller bearings enable shaft supports that can take heavy loads
  • They are insensitive to impact loads and require minimal installation space
  • They are suitable for accommodating axial loads in one sense

All Features

Inner diameter
190 mm
Width
37 mm
Number of rows
1
Material (cage)
Brass (solid)
Outer diameter
240 mm
Bore diameter
190 mm
Cage
Machined metal
Reference speed
700 r/min
Basic static load rating
1,460 kN
Tolerance class
Normal
Bearing part
Complete bearing
Limiting speed
1,400 r/min
Axial load capability
Single-direction
Coating
Without
Basic dynamic load rating
310 kN
Thickness
37 mm
Outer diameter
240 mm
Material, bearing
Bearing steel
  • Brand SKF
  • EAN 7316572428818
  • Supplier number SKF 81138 M
