SKF

SKF FY 3. UTF Y ball bearing unit with flange square, d 76.2 mm, A 59 mm, J 152.5 mm

This article is not available

Key features according to our expert
  • Shaft diameter: 76,2 mm
  • Split: No
  • Material (bearing housing): Stainless steel
  • Material (bearing): Steel
  • High temperature: No
  • Bore type: Cylindrical
  • Shape (bearing housing): Square
Specifications / All features
  • Brand: SKF
  • EAN: 7316577417435
  • Supplier number: SKF FY 3. UTF
Shaft diameter
76,2 mm
Split
No
Material (bearing housing)
Stainless steel
Material (bearing)
Steel
High temperature
No
Bore type
Cylindrical
Shape (bearing housing)
Square
Lubricant
Grease
Bearing width, total
77.8 mm
Material, housing
Cast iron
Basic static load rating
53 kN
Number of bolt holes for fasteners
4
Sealing, bearing
Seal and flinger on both sides
Rubber seating ring
Without
Sealing type
Contact, standard
Centre distance between bolt holes
152.5 mm
Material, bearing
Bearing steel
Flanged housing type
Square
Retaining feature, inner ring
Set screws
Width, total
82.5 mm
Grease fitting
With
Note
Limiting speed with shaft tolerance h6
Sealing, unit
Without
Limiting speed
2,400 r/min
Fastening bolt hole type
Plain
Relubrication hole
With
Housing overall width
59 mm
Basic dynamic load rating
72.8 kN
Coating
Without
Housing type
Flanged
