SKF HMV 15E hydraulic nut M75x2

Supplier number: SKF HMV 15E | EAN 7316577080134
Recommended Retail Price €1,512.44
1,034.40 tax incl.
€854.88 excl. VAT (incl. all environmental contributions)
On order: delivered from 10/10/2026

  • Ordered before 20:00 - delivered as of 10/10/2026
  • Free shipping
  • Delivery by DHL
  • Delivered from Belgium


€1,034.40
tax incl.

Product information

Key features according to our expert

  • Outer diameter: 140 mm
  • Width: 38 mm
  • Thread size*: M75 x 2

Product description

Facilitates easy and quick application of the high drive-up forces required for mounting bearings on tapered seatings. The hydraulic nut can also be used for dismounting bearings mounted on either adapter or withdrawal sleeves.

  • Quick connection coupling can be fitted on the face or side of the nut
  • A spare set of piston seals and maintenance kit is included
  • Supplied with a quick connection coupling to fit the SKF hydraulic pumps
  • Equipped with eyebolts, two tommy bars and four mating holes on their front face

Documents

All Features

Outer diameter
140 mm
Width
38 mm
Thread size*
M75 x 2
Thread form
ISO 965/111-1980 tolerance class 6H
Piston area
4000
Maximum piston displacement
5
Connecting thread
M 75x2
Piston outer diameter
132
Piston width
5
Piston inner diameter
75.5
Product weight
3.4
Model
Metric thread
Outside diameter
140
Maximum pressure
80
  • Brand SKF
  • EAN 7316577080134
  • Supplier number SKF HMV 15E
