Product description:
- Tapered roller bearings have an inner and outer ring with tapered raceways between which tapered roller bodies are arranged
- Due to their design, tapered roller bearings are ideally suited for taking combined axial and radial loads
- The axial load carrying capacity of bearings is largely paid for by the contact angle
- The larger this angle is, the higher the axial load carrying capacity is
- Tapered roller bearings can generally be separated into the cone, consisting of the inner ring with cage and roller bodies and the cup (outer ring)
Key features according to our expert
-
Inner diameter: 304,8 mm
-
Width: 63,5 mm
-
Number of rows: 1
-
Outer diameter: 406,4 mm
Specifications / All features
-
Brand:
SKF
-
01380511
-
EAN:
7316572083956
-
Supplier number:
SKF LM 757049/010
- Inner diameter
- 304,8 mm
- Width
- 63,5 mm
- Number of rows
- 1
- Outer diameter
- 406,4 mm
- Arrangement of contact angle (double-row bearing)
- Not applicable
- Cage
- Sheet metal
- Width, outer ring
- 47.625 mm
- Lubricant
- None
- Reference speed
- 1,000 r/min
- Relubrication feature
- Without
- Matched arrangement
- No
- Basic static load rating
- 1,700 kN
- Bearing part
- Complete bearing
- Locating feature, bearing outer ring
- None
- Sealing
- Without
- Contact angle
- 16.400000000041 °
- Width, total
- 63.5 mm
- Width, inner ring
- 63.5 mm
- Limiting speed
- 1,300 r/min
- Bore diameter
- 304.8 mm
- Basic dynamic load rating
- 775 kN
- Coating
- Without
- Outside diameter
- 406.4 mm
- Bore type
- Cylindrical
