SKF PFD 72 steel sheet bearing housing with triangular flange for slot-in bearings 72 x 20 mm

SKF
Supplier number: SKF PFD 72 | EAN 7316571011554
Recommended Retail Price €24.58
11.95 tax incl.
€9.88 excl. VAT (incl. all environmental contributions)
On order: delivered from 21/10/2026
set

The minimum purchase order quantity for the product is 10.

  • Ordered before 20:00 - delivered as of 21/10/2026
  • Shipping costs €6.99 VAT included | Free shipping for orders over a total amount of 125 euros
  • Delivery by DHL
  • Delivered from Belgium
↓ Documents (1) ✆ Talk to a specialist


Product information
€11.95
tax incl.

Product information

Key features according to our expert

  • Seat diameter: 72 mm
  • Shape (bearing housing): Triangle
  • Material (bearing housing): Sheet steel

Product description

Triangular flanged pressed steel housings for insert bearings are lightweight and made from cold-rolled steel, and are zinc-coated for corrosion protection. The housings are cost-effective and designed for simple applications with light loads. The two-part housing, which has no provision for relubrication, can be ordered separately from the insert bearing, making a large number of combinations possible.

  • Lightweight
  • Cost-effective
  • Flexible bearing and housing combinations
  • Simple to mount
  • Protection against corrosion

Documents

⤓ Technical data sheet PDF

All Features

Seat diameter
72 mm
Shape (bearing housing)
Triangle
Material (bearing housing)
Sheet steel
Grease fitting
Without
Spherical seating diameter
72
Housing type
Flanged
Flanged housing type
Triangular
Number of bolt holes for fasteners
3
Pitch diameter of bolt holes of round and triangle flange type housing
100
Relubrication hole
Without
Fastening bolt hole type
Plain
Coating
Zinc-coated
Material, housing
Pressed steel
  • Brand SKF
  • EAN 7316571011554
  • Supplier number SKF PFD 72
