SKF

SKF SA 30 TXE-2LS rod head, maintenance-free, sealed, male thread

Recommended Retail Price €503.34
249.20 tax incl.
€205.95 excl. VAT (incl. all environmental contributions)
On order: delivered from 26/05/2026
each

  • Ordered before 20:00 - delivered as of 26/05/2026
  • Free shipping
  • Delivery by DHL
  • Delivered from Belgium

Product description

  • These SKF rod ends contain a spherical plain bearing with a steel/PTFE fabric sliding contact surface combination and a triple-lip, heavy duty contact seal on both sides. The bearing is maintenance-free. The male thread is available with a left- (prefix SAL) or right-hand thread. Some sizes have different fitting dimensions (SA(L)A series).

Avantages

  • Long service life
  • Maintenance-free
  • Suitable for very heavy, constant direction loads
  • Low coefficient of friction
  • Simple and ready-to-mount
Key features according to our expert
  • Seal (bearing): Double-sided sealed
  • Maintenance free: Yes
Specifications / All features
  • Brand: SKF
  • EAN: 7316579881241
  • Supplier number: SKF SA 30 TXE-2LS
Seal (bearing)
Double-sided sealed
Maintenance free
Yes
Thread designation
M 30x2
Attachment feature, rod end shank
Right-hand male thread
Material, outer ring
Bearing steel
Centre height, housing (from end of shank)
110 mm
Sealing type
Triple-lip
Outside diameter, housing eye
75 mm
Bore diameter, bearing inner ring
30 mm
Basic static load rating
104 kN
Material, housing
Steel
Maintenance
Maintenance-free
Material, inner ring
Bearing steel
Width, bearing inner ring
22 mm
Sealing
Seal on both sides
Sliding contact surface combination
Steel/PTFE fabric
Width, housing eye
20 mm
Basic dynamic load rating
176 kN
Housing length, total
149 mm
