What type of thread does this SKF rod end have?

The rod end has a left-hand metric male thread sized M12.

What is the bore diameter of this rod end?

The inner bore diameter of this rod end is 12 mm.

Is the SKF SAL 12 E maintenance-free?

No, this model features a steel-on-steel sliding contact surface and requires regular relubrication.

Does this rod end feature integrated seals?

No, this rod end has an open design without seals.

What types of loads is this rod end suitable for?

It is designed to handle heavy static, alternating, and dynamic loads in mechanical linkages.

SKF SAL 12 E Rod head with male thread, left-hand thread 12 mm, M 12

Supplier number: SKF SAL 12 E | EAN 7316577003423

Recommended Retail Price €103.52

51.20 tax incl.

€42.31 excl. VAT (incl. all environmental contributions)

On stock - immediately available | we have 2 products in stock.

Ordered before 20:00 - delivered tomorrow 09/10/2026
Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL
Delivered from Belgium

↓ Documents (1) ✆ Talk to a specialist

Reliable motion transfer with the Skf rod end

Practical benefits

Handles heavy alternating loads: The steel-on-steel sliding contact surface reliably supports heavy static and dynamic stresses during demanding operation.
Accurate left-hand mounting: The M12 male left-hand thread lets you achieve a direct, secure fit within your linkage mechanisms.
Convenient side relubrication: You can easily inject grease through the designated side port to maintain smooth articulated movement.

In a nutshell

The right choise for

Achieve dependable motion and force transfer in your mechanical linkages with the Skf sal 12 e rod end. Featuring a 12 mm bore diameter and an M12 left-hand male thread, it compensates for angular misalignments between moving components. Its durable steel-on-steel sliding contact surface is built to handle heavy static, dynamic, and alternating loads across machinery, automotive applications, and hydraulic cylinder assemblies. Thanks to the dedicated side lubrication port, you can carry out routine relubrication quickly, ensuring smooth operation and dependable mechanical control.

Product information FAQ

€51.20

In stock - tax incl.

Key features according to our expert

Inner diameter: 12 mm
Connection type: External thread
Thread type: Metric - Left
Sealing (bearing): Without seals
Maintenance free: Nein
Connection size: M12

Product description

These SKF rod ends contain a spherical plain bearing with a steel/steel sliding contact surface combination. The bearing requires maintenance and can be relubricated only from the side. The male thread is available with a left- (prefix SAL) or right-hand thread.

Suitable for heavy static, alternating or impact loads
Simple and ready-to-mount

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter: 12 mm
Connection type: External thread
Thread type: Metric - Left
Sealing (bearing): Without seals
Maintenance free: Nein
Connection size: M12
Bore diameter, bearing inner ring: 12
Attachment feature, rod end shank: Left-hand male thread
Material, housing: Steel
Sliding contact surface combination: Steel/steel, standard
Housing length, total: 73
Maintenance: Relubrication required
Thread designation: M 12
Material, outer ring: Bearing steel
Outside diameter, housing eye: 35
Sealing: Without
Basic static load rating: 24.5
Material, inner ring: Bearing steel
Width, bearing inner ring: 10
Width, housing eye: 8.5
Basic dynamic load rating: 10.8
Centre height, housing (from end of shank): 54

Brand SKF
01390408
EAN 7316577003423
Supplier number SKF SAL 12 E

Frequently asked questions about this product

Answered by specialists

What type of thread does this SKF rod end have?: The rod end has a left-hand metric male thread sized M12.
What is the bore diameter of this rod end?: The inner bore diameter of this rod end is 12 mm.
Is the SKF SAL 12 E maintenance-free?: No, this model features a steel-on-steel sliding contact surface and requires regular relubrication.
Does this rod end feature integrated seals?: No, this rod end has an open design without seals.
What types of loads is this rod end suitable for?: It is designed to handle heavy static, alternating, and dynamic loads in mechanical linkages.
