SKF

SKF SIKB 12 F/VZ019 Rod head with female thread 12 mm, M 12x1.25

Recommended Retail Price €100.79
49.80 tax incl.
€41.16 excl. VAT (incl. all environmental contributions)
On order: delivered from 30/05/2026
each

  • Ordered before 20:00 - delivered as of 30/05/2026
  • Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
  • Delivery by DHL
  • Delivered from Belgium

Product description

These SKF rod ends have an injection moulded sliding layer of PTFE FRP between the housing and the inner ring. This sliding contact surface combination is maintenance-free. The male thread is available with a left- (prefix SAL) or right-hand thread.

  • Long service life
  • Maintenance-free
  • Relatively insensitive to contaminants
  • Low coefficient of friction
  • Simple and ready-to-mount
Key features according to our expert
  • Inner diameter: 12 mm
  • Connection type: Inner thread
  • Thread type: Metric fine
  • Seal (bearing): Without seal
  • Maintenance free: Yes
  • Connection size: M12 x 1,25
Specifications / All features
  • Brand: SKF
  • EAN: 7316570953596
  • Supplier number: SKF SIKB 12 F/VZ019
Inner diameter
12 mm
Connection type
Inner thread
Thread type
Metric fine
Seal (bearing)
Without seal
Maintenance free
Yes
Connection size
M12 x 1,25
Basic static load rating
17
Attachment feature, rod end shank
Right-hand female thread
Material, housing
Steel
Sliding contact surface combination
Steel/PTFE FRP
Housing length, total
68
Maintenance
Maintenance-free
Thread designation
M 12x1.25
Outside diameter, housing eye
33
Bore diameter, bearing inner ring
12
Sealing
Without
Material, inner ring
Bearing steel
Width, bearing inner ring
16
Width, housing eye
12.5
Basic dynamic load rating
13.2
Centre height, housing (from end of shank)
50
