SKF SILKAC 30 M Rod head with female thread, left-hand thread 30 mm, M 30x2

SKF
Supplier number: SKF SILKAC 30 M | EAN 7316570793789
Recommended Retail Price €558.38
276.40 tax incl.
€228.43 excl. VAT (incl. all environmental contributions)
On order: delivered from 22/10/2026

  • Ordered before 20:00 - delivered as of 22/10/2026
  • Free shipping
  • Delivery by DHL
  • Delivered from Belgium
↓ Documents (1) ✆ Talk to a specialist


Product information
€276.40
tax incl.

Product information

Key features according to our expert

  • Inner diameter: 30 mm
  • Connection type: Internal thread
  • Thread type: Metric fine - Left
  • Sealing (bearing): Without seals
  • Maintenance free: Nein
  • Connection size: M30 x 2

Product description

These SKF rod ends contain a spherical plain bearing with a steel/bronze sliding contact surface combination. The bearing requires maintenance, sizes 6 and larger can be relubricated via a grease fitting in the housing and via the shank. The female thread is available with a left- (prefix SIL) or right-hand thread.

  • Suitable where lubricant starvation might occur
  • Simple and ready-to-mount
  • Easy to relubricate (sizes >= 6)

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter
30 mm
Connection type
Internal thread
Thread type
Metric fine - Left
Sealing (bearing)
Without seals
Maintenance free
Nein
Connection size
M30 x 2
Basic static load rating
69.5
Attachment feature, rod end shank
Left-hand female thread
Material, housing
Steel
Sliding contact surface combination
Steel/bronze
Housing length, total
146
Maintenance
Relubrication required
Thread designation
M 30x2
Outside diameter, housing eye
71
Bore diameter, bearing inner ring
30
Sealing
Without
Material, inner ring
Bearing steel
Width, bearing inner ring
37
Width, housing eye
27
Basic dynamic load rating
64
Centre height, housing (from end of shank)
110
  • Brand SKF
  • EAN 7316570793789
  • Supplier number SKF SILKAC 30 M
