SKF SILKAC 6 M rod head with female thread, left-hand thread, M 6

SKF
Supplier number: SKF SILKAC 6 M | EAN 7316577104328
Recommended Retail Price €76.15
37.60 tax incl.
€31.07 excl. VAT (incl. all environmental contributions)
On order: delivered from 14/10/2026

  • Ordered before 20:00 - delivered as of 14/10/2026
  • Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
  • Delivery by DHL
  • Delivered from Belgium
↓ Documents (1) ✆ Talk to a specialist


Product information
€37.60
tax incl.

Product information

Key features according to our expert

  • Inner diameter: 6 mm
  • Connection type: Internal thread
  • Thread type: Metric - Left
  • Sealing (bearing): Without seals
  • Maintenance free: Nein
  • Connection size: M6

Product description

These SKF rod ends contain a spherical plain bearing with a steel/bronze sliding contact surface combination. The bearing requires maintenance, sizes 6 and larger can be relubricated via a grease fitting in the housing and via the shank. The female thread is available with a left- (prefix SIL) or right-hand thread.

  • Suitable where lubricant starvation might occur
  • Simple and ready-to-mount
  • Easy to relubricate (sizes >= 6)

Documents

⤓ Technical data sheet PDF

All Features

Inner diameter
6 mm
Connection type
Internal thread
Thread type
Metric - Left
Sealing (bearing)
Without seals
Maintenance free
Nein
Connection size
M6
Basic static load rating
5.4
Attachment feature, rod end shank
Left-hand female thread
Material, housing
Steel
Sliding contact surface combination
Steel/bronze
Housing length, total
41
Maintenance
Relubrication required
Thread designation
M 6
Outside diameter, housing eye
21
Bore diameter, bearing inner ring
6
Sealing
Without
Material, inner ring
Bearing steel
Width, bearing inner ring
9
Width, housing eye
7.5
Basic dynamic load rating
4.3
Centre height, housing (from end of shank)
30
  • Brand SKF
  • EAN 7316577104328
  • Supplier number SKF SILKAC 6 M
