Which shaft diameter is the SKF TUJ 60 TF take-up unit designed for?

This unit is designed for shafts with a diameter of 60 mm.

How is the bearing secured to the shaft?

You lock the bearing onto the shaft using set screws on the extended inner ring.

What materials are used in this unit?

The housing is made of cast iron and the insert bearing is made of bearing steel.

Can this take-up unit be relubricated?

Yes, the cast iron housing is equipped with a grease fitting for routine maintenance.

Which industry standard does this unit comply with?

The TUJ 60 TF unit complies with the JIS standard.

SKF TUJ 60 TF ball bearing unit 60 mm

Supplier number: SKF TUJ 60 TF | EAN 7316570800784

Recommended Retail Price €410.82

203.40 tax incl.

€168.10 excl. VAT (incl. all environmental contributions)

On stock - immediately available | we have 6 products in stock.

Ordered before 20:00 - delivered tomorrow 10/10/2026
Free shipping
Delivery by DHL
Delivered from Belgium

↓ Documents (1) ✆ Talk to a specialist

Reliable tensioning with Skf

Practical benefits

Fast and secure mounting: You lock the extended inner ring easily onto the shaft with the built-in set screws.
Rugged cast iron housing: The heavy-duty housing provides you with dependable strength and rigidity under high mechanical loads.
Effective bearing protection: You avoid premature wear thanks to contact seals that keep dirt out and grease locked inside.

In a nutshell

The right choise for

With the Skf tuj 60 tf take-up unit, you tension and align shafts in conveyor systems and industrial power drives without disassembling the assembly. Engineered to the jis standard for 60 mm shafts, this unit features an extended inner ring with set screw locking, allowing you to secure the bearing steel insert quickly and prevent shaft slippage. The heavy-duty cast iron housing provides dependable mechanical strength and vibration damping under demanding operating conditions. Effective contact seals protect the bearing from dirt, while the built-in grease fitting ensures hassle-free routine relubrication.

Product information FAQ

€203.40

In stock - tax incl.

Key features according to our expert

Shaft diameter: 60 mm
Material (bearing housing): Cast iron
Material (bearing): Steel

Product description

Take-up ball bearing units, consisting of an insert bearing based on a sealed deep groove ball bearing mounted in a grey cast iron housing. Typically mounted in take-up frames, the unit has an inner ring extended on both sides and is locked by tightening a (set) screw on the inner ring, which makes it easy to mount.

Designed for an alternating rotation
Quick and easy to mount onto the shaft
Accommodate static initial misalignment
Long service life
Reduced noise and vibration levels

Documents

⤓ Technical data sheet PDF

All Features

Shaft diameter: 60 mm
Material (bearing housing): Cast iron
Material (bearing): Steel
Material, housing: Cast iron
Grease fitting: With
Tightening torque, set screw: 16.5
Hexagonal key size for set screw: 5
Note: Limiting speed with shaft tolerance h6
Application: For material handling applications
Housing type: Take-up
Bore type: Cylindrical
Material, bearing: Bearing steel
Sealing, bearing: Seal and flinger on both sides
Sealing type: Contact, standard
Rubber seating ring: Without
Lubricant: Grease
Bearing width, total: 65.1
Basic static load rating: 36
Retaining feature, inner ring: Set screws
Sealing, unit: Without
Limiting speed: 3400
Relubrication hole: With
Housing overall width: 60
Basic dynamic load rating: 52.7
Coating: Without
Set screw: M10x1

Brand SKF
01193034
EAN 7316570800784
Supplier number SKF TUJ 60 TF

Frequently asked questions about this product

Answered by specialists

Which shaft diameter is the SKF TUJ 60 TF take-up unit designed for?: This unit is designed for shafts with a diameter of 60 mm.
How is the bearing secured to the shaft?: You lock the bearing onto the shaft using set screws on the extended inner ring.
What materials are used in this unit?: The housing is made of cast iron and the insert bearing is made of bearing steel.
Can this take-up unit be relubricated?: Yes, the cast iron housing is equipped with a grease fitting for routine maintenance.
Which industry standard does this unit comply with?: The TUJ 60 TF unit complies with the JIS standard.
