WERA 1461 ESD Kraftform Micro adjustable torque screwdriver standard setting (0.02-0.11 Nm) with quick change holder 0.050 Nm - 05074810001

Scope of delivery

• 1460 ESD Kraftform Micro torque screwdrivers, with factory pre-set value (0.02-0.11 Nm) and quick-release chuck, 1461 ESD x 0.050 Nm

Product description

With a factory pre-set torque value set to the smallest scale value. For all applications, where the same constant torque and repeat accuracy are required. Compact handle/interchangeable blades system for torque-controlled precision screwdriving. The Kraftform Micro ESD torque screwdriver is ideal for torque-controlled jobs on electrostatically sensitive components. Suitable for bits with a 4 mm Halfmoon drive (Wera series 9) and a 4 mm HIOS drive (Wera series 21). Tamper-proof. Clearly audible and tactile signal when the set torque is reached. Repeatability is 100% guaranteed. Unlimited manual loosening torque. Electrical surface resistance<= 10⁹ ohms for safe protection against electrostatic charge. Manufactured as per DIN EN 61340-5-1. Handle/interchangeable blades system for rapid blade changes. Kraftform Micro handle with rotating cap and free-turning zone for rapid turning, making any time-consuming repositioning of the fingers unnecessary. Power zone with integrated soft zones ensures the transmission of high tightening and loosening torques. Precision zone directly above the blade for the correct rotation angle for adjustment work. Rapid bit fixing: Simply push the bit into the holder for automatic locking and a secure fit. To change the bit, simply push the sleeve forward and remove the bit. Free-running actuating sleeve for easy handling of the tool during the screwdriving process. Bits suitable for manual and machine operated screwdriving connections with electric screwdrivers (including HIOS, Delvo, Sehan). Use with e.g. smartphones, mobile phones, cameras, electronic devices, in dental laboratories and dental surgeries.
Please note: 1 Ncm = 0.01 Nm.

• Factory pre-set, adjustable Kraftform Micro ESD torque screwdriver with quick-release chuck
• ESD-safe tool thanks to surface resistance of<= 10⁹ Ohm
• Distinct audible and perceivable excess load signal when the pre-set torque value is reached
• Suitable for the take-up of bits with 4 mm halfmoon drive and 4 mm HIOS drive
• Applications e.g. on smartphones, mobile phones, cameras, electronic equipment

Application

• Suitable for bits with 4 mm Halfmoon drive (and Wera Serie 9) and 4 mm HIOS drive (and Wera Series 21)

Design

• With quick-release chuck for rapid bit change

Pre-set torque

• 0,035 Nm, 0,05 Nm

Accuracy

• ± 10%. Reliable slipping mechanism and acoustic signal when reaching the set torque.

Handle

• Kraftform Micro with non-roll feature and rotating cap, multi-component

Features and benefits

• Wera torque screwdrivers. With a factory pre-set torque value set to the smallest scale value. For all applications, where the same constant torque and repeat accuracy are required.
• The requirements for ESD-safe screwdrivers are specified in the European standard DIN EN 61340-5-1. This standard also includes a handle that has to be out of a defined conductive material. The Wera products in the ESD series satisfy these standards and the even more stringent requirements demanded by some technology companies.
• The electric surface resistance of the Wera ESD material is<= 10⁹ ohm. This securely protects components against electrostatic energy and associated damage.
• Features a combination bit holder for both bits with Halfmoon and bits with HIOS drive.
• The power zone has integrated soft zones near the blade tip to ensure high torque transfer for loosening or tightening screws without losing contact with the screw.
• The precision zone directly above the blade gives the user a better feel for the right rotation angle during fine adjustment work.
• The fast-turning zone just below the rotating cap allows rapid spinning.
