GEDORE 1.18/3 trigger 2-arm 200x200 mm - 1464981

Show more features

Max. width

200 mm

Number of hooks

2

Hydraulical

No

Max. height

200 mm

Reversible arms available

No

Clamping bracket available

No

Hook foot thickness at end e1 [mm]

7.5 mm

Hook foot depth usable d2 [mm]

22 mm

Suitable for use with a hydraulic spindle

No

Hydraulic spindle optional

1.06/HSP1

Screws included

No

Hook foot width on the gripping surface c1 [mm]

22 mm

Number of arms

2

Spindle thread size

G 1/2 x 282

Towing force (max.) [t]

5

Drive hexagonal width

22 mm

Hook brake available

No

Span when pulled externally (max) [mm].

200 mm

Spindle-slide protection

No

Clamping depth usable b [mm]

200 mm
