Application Controlled screw tightening in the range 5 - 25 Nm / 3.7 - 18 lbf-ft
Adjustable, audible and tactile switch-off robust torque spanner with round pin take-up
Design Classified according to DIN EN ISO 6789-22017 Type II Class A, calibrated with a maximum permissible deviation of +/- 3% and thus more accurate than the +/- 4% required by the standard
Including traceable test certificate (DIN EN ISO 6789-22017)
Tbv controlled right- and left-hand tightening (reversing insertion tool for changing direction)
Pin holder Ø 16 mm
Working calibration distance 32 mm (Ø 16 mm)
Robust, matt powder-coated steel pipe construction and high-quality plastic parts
New ergonomic handle, shaped according to the natural grip position of the hand
Clearly identifiable, hand-feelable, centring and calibration aid in the middle of the handle
Double scale Nm / lbf-ft with vernier (Nm), enlarged viewing window protects against dirt and damage
With vernier scale for Nm main scale for setting intermediate scale values
Lbf-ft setting via main scale only
Vertical arrangement of scale, thus suitable for left- and right-handed users
Setting mark directly above scale, prevents reading errors (parallax error)
Unit marking integrated in the scale and also protected from dirt by viewing window
Precise turn-off mechanism generates a clear tactile and audible signal when the set tightening value is reached
Includes roll-off safety device, prevents rolling away when the spanner is put down
