MITUTOYO 468-175 Digimatic 3-point internal caliper 125-150m

Name: MITUTOYO 468-175 Digimatic 3-point internal caliper 125-150m
Brand: MITUTOYO
SKU: 41010438
Price: 2152.49 EUR
Availability: PreOrder

Supplier number: MITUTOYO 468-175 | EAN 4946368563077

2,152.49 tax incl.

€1,778.92 excl. VAT (incl. all environmental contributions)

On order: delivered from 08/10/2026

Ordered before 20:00 - delivered as of 08/10/2026
Free shipping
Delivery by DHL
Delivered from Belgium

✆ Talk to a specialist

Precise internal bore measurement with Mitutoyo

Practical benefits

Reliable self-centering bore measurement: You achieve consistent alignment inside bores from 125 to 150 mm thanks to the three evenly spaced measuring anvils.
Titanium-coated anvils for durability: The titanium nitride coating provides superior wear resistance and impact protection, keeping contact surfaces accurate over heavy use.
Clear digital display and protection: You read measurements clearly on the large LCD screen, while the IP65 housing protects your instrument from dust and coolants.

In a nutshell

The right choise for

With the Mitutoyo 468-175, you carry out highly reliable internal bore measurements from 125 to 150 mm. Thanks to the self-centering three-point measuring method, you align the tool accurately inside cylindrical bores and prevent tilt errors during quality inspections. The titanium nitride coated contact points deliver exceptional wear resistance for demanding machining environments. You read results clearly on the large lcd display with a 0.001 mm resolution and ±0.005 mm accuracy. Furthermore, the IP65 rating safeguards the instrument against dust and coolant splash, while the Digimatic data output allows straightforward data transfer using an optional spc cable.

Product information FAQ

€2,152.49

tax incl.

Key features according to our expert

Micrometer type: Inside micrometer
Min. measuring value: 125 mm
Max. measuring value: 150 mm
Scale division: 0,001 mm mm

Product description:

These are three-point internal screw gauges that offer you the following advantages:
- Individual inner screw gauge.
- Titanium-coated measuring tips give excellent durability and shock resistance.
- Also excellent resistance to water and dust (IP65 protection class) that allows this product to be used in machine conditions with splashing coolants.
- Large LCD display with character height of 7.5 mm allows easy reading.
- Without setting rings or extensions.

All Features

Micrometer type: Inside micrometer
Min. measuring value: 125 mm
Max. measuring value: 150 mm
Scale division: 0,001 mm mm

Brand MITUTOYO
41010438
EAN 4946368563077
Supplier number MITUTOYO 468-175

Frequently asked questions about this product

Answered by specialists

What is the measuring range of this internal micrometer?: This micrometer covers an inside measurement range of 125 to 150 mm.
What resolution and accuracy does this gauge offer?: The digital display has a 0.001 mm resolution with an accuracy of ±0.005 mm.
Is this instrument protected against dust and fluids?: Yes, the IP65 rating provides protection against dust ingress and coolant splashing.
Are the contact points wear-resistant?: Yes, the measuring anvils feature a durable titanium nitride (TiN) coating.
Can measurement values be transferred to a computer?: Yes, it includes a Digimatic data output for transfer using an optional SPC cable.
