MITUTOYO

MITUTOYO 523-124 compass gauge with dial 75-100mm/0.001mm

940.80 tax incl.
€777.52 excl. VAT (incl. all environmental contributions)
On order: delivered from 27/08/2026
each

  • Ordered before 20:00 - delivered as of 27/08/2026
  • Free shipping
  • Delivery by DHL
  • Delivered from Belgium

Product description:

  • This Snap Gauge designed to mount an indicator to suit the measurement
  • Application, and offers the following benefits:
    • It's ideal for rapidly inspecting workpieces, especially cylindrical, in batch or mass production situations, when you need an indication of where a measurement falls within the tolerance band.
    • You can set it with external length standards such as block gauges.
    • Easy-to-operate retracting button.
Key features according to our expert
  • Micrometer type: Outside micrometer
  • Min. measuring value: 75 mm
  • Max. measuring value: 100 mm
  • Scale division: 0,001 mm mm
Specifications / All features
  • Brand: MITUTOYO
  • EAN: 4946368380308
  • Supplier number: MITUTOYO 523-124
Micrometer type
Outside micrometer
Min. measuring value
75 mm
Max. measuring value
100 mm
Scale division
0,001 mm mm
