What is the measuring range of this depth dial gauge?

The total measuring range is 0 to 210 mm, achieved using the included extension rods.

What graduation and accuracy does this gauge provide?

The dial indicator features a 0.01 mm graduation and an accuracy of ± 30 µm.

What are the base dimensions of the gauge?

The rectangular base measures 63.5 mm in width and 16 mm in thickness.

What contact point tip comes with the Mitutoyo 7213A?

It features a carbide-tipped spherical ball contact point with a 1.5 mm radius.

Which extension rods are included with the gauge?

It comes with three extension rods measuring 30 mm, 60 mm, and 90 mm.

MITUTOYO 7213A dial gauge for depth measurement 0-210mm with ball-shaped contact point bridge piece 63,5mm

Name: MITUTOYO 7213A dial gauge for depth measurement 0-210mm with ball-shaped contact point bridge piece 63,5mm
Brand: MITUTOYO
SKU: 03219800
Price: 314.95 EUR
Availability: PreOrder

Supplier number: MITUTOYO 7213A | EAN 4946368851839

314.95 tax incl.

€260.29 excl. VAT (incl. all environmental contributions)

On order: delivered from 14/10/2026

Ordered before 20:00 - delivered as of 14/10/2026
Free shipping
Delivery by DHL
Delivered from Belgium

✆ Talk to a specialist

Precise inspection with Mitutoyo

Practical benefits

Reliable high measuring precision: With 0.01 mm graduation and ± 30 µm accuracy, you obtain consistent and exact readings.
Stable hardened base plate: The 63.5 mm reference base provides you with a flat, stable platform on workpieces.
Wide range to 210 mm: You easily measure different hole depths, steps, and narrow slots up to 210 mm.

In a nutshell

The right choise for

With the Mitutoyo 7213A depth dial gauge, you accurately inspect holes, slots, and machined cavities in the workshop or metrology lab. Thanks to its 0.01 mm graduation and ± 30 µm accuracy, you obtain dependable measurements on critical dimensions. The hardened reference base, measuring 63.5 mm wide and 16 mm thick, provides a flat and stable resting surface on your workpiece. Its spherical ball contact point ensures consistent readings even on curved or uneven bottom surfaces. Using the included 30 mm, 60 mm, and 90 mm extension rods, you effortlessly cover a wide measuring range from 0 to 210 mm.

Product information FAQ

€314.95

tax incl.

Key features according to our expert

Max. measuring value: 210 mm
Scale: 0,01 mm
Accuracy: ± 30 µm

Product description

Depth gauge with measuring bell and rectangular bridge piece
Hardened, precision ground and lapped reference surface on the bridge piece.

All Features

Max. measuring value: 210 mm
Scale: 0,01 mm
Accuracy: ± 30 µm

Brand MITUTOYO
03219800
EAN 4946368851839
Supplier number MITUTOYO 7213A

Frequently asked questions about this product

Answered by specialists

What is the measuring range of this depth dial gauge?: The total measuring range is 0 to 210 mm, achieved using the included extension rods.
What graduation and accuracy does this gauge provide?: The dial indicator features a 0.01 mm graduation and an accuracy of ± 30 µm.
What are the base dimensions of the gauge?: The rectangular base measures 63.5 mm in width and 16 mm in thickness.
What contact point tip comes with the Mitutoyo 7213A?: It features a carbide-tipped spherical ball contact point with a 1.5 mm radius.
Which extension rods are included with the gauge?: It comes with three extension rods measuring 30 mm, 60 mm, and 90 mm.
